Tsev Cov khoom Carbonization Rauv Paub meej

Charcoal Powder Charcoal Rauv

Cov khoom siv raw khoom rau cov khoom siv hluav taws xob carbonization tau dav thiab nrhiav tau yooj yim, ua rau koj xaiv zoo tshaj plaws.

Xa kev nug

Muaj nuj nqi

Cov cuab yeej ntsuas

Lub hoisting carbonization rauv yog ib yam khoom tshiab. Nws suav nrog lub tshuab ua kom sov, lub qhov cub npog, lub tshuab cua sov, thiab cov yeeb nkab tso pa. Lub carbonization liner yog ntsia rau hauv lub qhov cub ntawm lub qhov cub lub cev, thiab ib lub hau yog ntsia rau ntawm carbonization liner. Lub ntug sab sauv ntawm carbonization liner yog tsau nrog downward-folded annular flange, thiab downward-folded annular flange yog txuam nrog lub annular sealing nplhaib tsau rau sab sauv sab hauv ntawm lub cub tawg. Sab phab ntsa ntawm carbonization liner, lub hau ntawm lub carbonization liner, thiab lub qhov cub npog yog feem ntau kho nrog hoisting pob ntseg. Lub qhov cub carbonization tshiab tau sib cais los ntawm lub combustion chamber thiab txais yuav cov pa roj carbonization liner kom ua tiav kev ua haujlwm tas mus li. Ib lub cub tawg tuaj yeem nruab nrog ntau cov pa roj carbonization. Thaum hloov cov carbonization liner, tsis tas yuav tsum tau kho preheating. Cov cua txias ntawm carbonization liner yog cais tag nrho los ntawm lub qhov cub lub cev, yog li txhim kho cov carbonization ua hauj lwm efficiency.

Khoom Parameters

Qauv	Internal chim loj	Outer chim loj
150	0.8×1.5	1.8×1×1.6
200	1×1.5	1.8×1.2×1.6
300	1.2×1.5	1.8×1.2×1.4
500	1.5×1.5	1.8×1.7×2.2
1000	1.3×3	3.2×1.6×2.4
2000	1.5×4	4.2×1.9×2.4
3000	1.9×4.5	4.8×2.3×2.8

Khoom Taw Qhia

Muab cov taws teeb taws lossis cov ceg ntoo uas muaj qhov ua kom siab dua los ntawm cov nqaj ua rau lub tshuab hluav taws xob tuaj yeem nkag mus rau hauv qhov cub ua kom hnyav, npog nws, thiab zes nws. Thaum lub sij hawm cua sov txheej txheem, cov roj combustible yuav raug tsim nyob rau hauv lub peev xwm, thiab cov gases yuav raug xa rov qab mus rau lub cub tawg los ntawm cov roj sau yeeb nkab rau combustion. Ib lub qhov cub tuaj yeem tuav tau peb lub kaus poom tib lub sijhawm, thiab cov roj hluav taws xob uas tsim los ntawm peb lub kaus poom yog txuas nrog cov roj sib txuas thiab tuaj yeem sib txuas. Nyob rau hauv txoj kev no, peb retorts tau muab tso rau tib lub sijhawm, thiab tsuas yog hauv qab ntawm ib lub kaus poom yuav tsum tau ua kom sov, thiab cov khoom tiav tuaj yeem carbonized hauv 7-10 teev. Tom qab ntawd tuav lub retort tawm, txias rau 10 teev, thiab qhib lub qhov cub kom tau lub tshuab ua hluav taws xob tiav. (Ib zaug ignited, ntev npaum li ib tus tuaj yeem ua haujlwm, tsis tas yuav ntxiv roj, thiab cov pa roj ntau dhau tuaj yeem txuas nrog rau lwm cov retorts los ntawm cov roj sib sau cov yeeb nkab siv).

Ib puag ncig tus phooj ywg tsis haus luam yeeb carbonization rauv yog cov khoom tshiab ntawm square carbonization cub. Nws siv lub hauv paus ntsiab lus ntawm qhuav distillation carbonization kom sov thiab decompose cov hluav taws nyob rau hauv lub cub tawg los tsim combustible gas thiab charcoal. Nws siv cov qauv hlau txav txav tau, thiab cov pa luam yeeb tso pa rau saum lub cub tawg yog txuas nrog lub tshuab cais thiab cov kiv cua induced hauv lem. Nws muaj qhov zoo ntawm cov qauv tsim nyog, loj ntim tau zoo, cov txheej txheem carbonization siab, lub voj voog luv luv, cov zis siab, kev tiv thaiv ib puag ncig zoo, thiab kev pabcuam ntev. Lub tank tshem tawm cov pa luam yeeb ib puag ncig tuaj yeem rov ua dua thiab tshem tawm cov tar thiab lwm cov pa luam yeeb thaum lub sij hawm carbonization los ntawm kev siv tshuaj thiab lub cev ib zaug, txo cov pa luam yeeb hauv huab cua thiab tiv thaiv kev ua qias tuaj.
